Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter

China Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter supplier
Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter supplier Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter supplier Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter supplier Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter supplier

Large Image :  Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter

Product Details:

Place of Origin: DONGUAN CHINA
Brand Name: ZONSKY
Certification: ISO9001:2008, CE, SGS, IAF
Model Number: ZY6012A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box
Delivery Time: 15 Working Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Set / Month
Detailed Product Description
Material: Paint Finish Standards: IEC, UL1581
Maximum Stroke: 100 Mm Workbench Specification: 300mm * 300mm
Effective Area: 300mm * 300mm Air Pressure: 0 - 0.6Mpa
High Light:

flammability test chamber

,

flammability testing labs

Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter



1. Application



ZY6012A pneumatic sample slicer is used for rubber factory and scientific research unit to punch the standard rubber test piece before the tensile test. For similar materials, the machine can also be die cut.



2. Main Technical Parameters



This machine is used to die-cut rubber, plastic, leather and other special materials into various standard test pieces for testing. It can also be used as a small punch.

(1) The maximum stroke: 100mm

(2) Workbench specifications: 300mm*300mm

(3) Effective area: 300mm*300mm

(4) The use of air pressure: 0 - 0.6Mpa



Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter



3. The structure is briefly described



The punching machine is mainly composed of: cylinder, vacuum gauge, base, yoke and platform.



4. Method Of Use



(1) Put a piece of cardboard on the platform of the base;

(2) placing the sample blank on the plane of the cardboard;

(3) Place the cutter on the specimen on the workbench so that the cutting edge plane is parallel to the platform of the base;

(4) Press the cutting knife to punch it into a standard sample.



5. Matters Needing Attention And Maintenance



(1) The plane of the punching cutting edge should be parallel to the plane of the table. When cutting, the cutting edge should not be in contact with the plane of the table, so as not to damage the cutting edge.

(2) After use, the punching cutter should be coated with anti-rust oil to prevent corrosion.

(3) Apply dust cover after use to prevent oil and dust from entering.



Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter

Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter

Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter

Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter

Pneumatic Wire And Cable Specimen Slicer / Paint Finish Pneumatic Dumbbell Cutter





FAQ



Q: Are you trading company or manufacturer ?

A: We are a manufacturer.



Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? Is it free or extra ?

A: No, we don't provide the samples for testing.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment.
If you have another question, please feel free to contact us.



Q: What is your terms of payment ?

A: The warranty for the equipment is 1 year. Definitely, all equipment are tested well and runs well by testing our customer's sample before shipment. Please contact us if the equipment doesn't work well after being shipped to your company. We will guide you how to fix it. The spare parts or components will be sent if necessary. The charges will be occurred if it is caused by customer's misoperation.
