Spring Type Tensile Strength Testing Equipment For Cable Durability Test

China Spring Type Tensile Strength Testing Equipment For Cable Durability Test supplier

Large Image :  Spring Type Tensile Strength Testing Equipment For Cable Durability Test

Product Details:

Place of Origin: DONGGUAN CHINA
Brand Name: ZONSKY
Certification: ISO9001:2008, CE, SGS, IAF
Model Number: ZY6005A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box
Delivery Time: 15 Working Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 Set / Month
Detailed Product Description
Material: Stainless Steel Standards: GB/T239
Speed Of Expansion: 0.33 M/s Sample Size: 5 Groups
Total Power: 1 KW Size: L1350 * W800 * H2550 MM
High Light:

tensile strength measuring machine

,

wire tensile testing machine

Spring Type Cable Durability Tester / Test Apparatus





1. Description



This machine meets the test conditions specified in the GB/T239-1999 GB/T4909.4-2009 standard. It is mainly used for the stretching durability test of spring cable used in electric vehicle conduction charging system. During the test, the sample is electrified and the mechanical stretching shrinks continuously. When the current interrupts or reaches the set number of times, the damaged part and the stretching times are inspected. The user should carefully read the standard and the instructions before using the machine. Be familiar with the performance of the machine so as to accurately use this machine to complete the spring type cable stretching and durability test.





2. Main Technical Parameters



(1) Work power supply: AC220V, 50HZ.



(2) Total power: 1 KW



(3) Sample size: 5 groups.



(4) Telescopic stroke: 300 - 1800mm adjustable



(5) Speed of expansion: 0.33 m/s



(6) Operation mechanism: gear reducer motor, drive chain drive.



(7) Motor power: 750W, 380V variable frequency speed regulation



(8) Control mode: touch screen +PLC



(9) Count: 0 - 999999 arbitrary settings



(10) Size: L1350 * W800 * H2550 MM





3. Test Notes



Take a suitable length of the finished spring cable and install it on the special stretching test machine. The stretching test machine can extend the length of the spring cable to three times the natural length and start stretching movement. The speed of stretching operation is 0.33m/s, and the reciprocating stretching movement is 30000 times.





4. Matters Needing Attention



(1) The equipment must be placed on a stable, strong ground and should not be tilted.



(2) When the equipment is in use, it must be grounded reliably to avoid electric shock.



(3) The environment for this equipment should be dry and wet, so as to prevent equipment from being rusted.



(4) If the equipment is not used for a long time, it is necessary to energized the equipment regularly to prevent circuit faults.



(5) Timely sorting out test equipment to keep the equipment clean.
