ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester

China ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester supplier
ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester supplier ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester supplier ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester supplier ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester supplier

Large Image :  ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester

Product Details:

Place of Origin: DONGUAN CHINA
Brand Name: ZONSKY
Certification: ISO9001:2008, CE, SGS, IAF
Model Number: ZY6011A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box
Delivery Time: 15 Working Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Set / Month
Contact Now
Detailed Product Description
Material: Paint Finish Standards: UL1581, ASTM-D2436
Normal Temperature: +10 ℃ ~ 250℃ Inner Box Size: L500 X W500 X H500mm
Outer Box Size: L1123 X W730 X H1427mm Power: 6 KW
High Light:

flammability test chamber

,

flammability testing labs

ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester​



1. Application



ZY6011A ventilation type aging test machine, this machine is suitable for wire, leather, plastic, rubber, cloth, before and after heating. In order to maintain the fresh air in the box when the electric wire is heated, the special ventilation amount is adjusted.



2. Implementation of Standards



The instrument is designed to meet the requirements of UL1581, ASTM-D2436, CNS3556, CNS742, JIS7212, JIS B7757, GB, VDE test standards.



ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester



3. Use Condidtions



(1) Power supply: AC 380V 50Hz

(2) Ambient temperature: 5~35℃

(3) Ambient humidity: ≤85% R.H



4. Performance Indicators



(1) Power supply: AC380V, 50HZ

(2) Power: 6.0KW

(3) Temperature range: normal temperature +10 ℃ ~ 250℃

(4) Control accuracy: ±0.5℃

(5) Analysis accuracy: 0.1℃

(6) Heating time: from normal temperature to 250℃, about 40 minutes.

(7) Inner box size: L500mm x W500mm x H500mm

(8) Outer box size: L1123mm x W730mm x H1427mm

(9) Inner box material: SUS#304 stainless steel, outer box paint

(10) Insulation material: high density rock wool



ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester

ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester

ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester

ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester

ASTM D2436 Air Ventilation Aging Test Chamber / Ventilation Type Aging Oven / Rubber Plastic Heat Resistance Tester





FAQ



Q: Are you trading company or manufacturer ?

A: We are a manufacturer.



Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? Is it free or extra ?

A: No, we don't provide the samples for testing.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment.
If you have another question, please feel free to contact us.



Q: What is your terms of payment ?

A: The warranty for the equipment is 1 year. Definitely, all equipment are tested well and runs well by testing our customer's sample before shipment. Please contact us if the equipment doesn't work well after being shipped to your company. We will guide you how to fix it. The spare parts or components will be sent if necessary. The charges will be occurred if it is caused by customer's misoperation.
